Hum-Cancelling P90

(98 customer reviews)

$145.00$290.00

Are you still searching for that noiseless P90 tone that sounds like a real P90? Your search has ended: introducing the Fralin Hum Cancelling P90. With a unique coil design and magnet structure, the Fralin Hum Cancelling P90 provides a versatile, hum-free tone that cleans up and gets dirty, with plenty of articulation and clarity. Read more to find your guitar’s real voice:

PRODUCT OPTIONS:
Clear

Pickup Cover (Required) *

Please choose how you want your pickups to look in your guitar.

Shim for Dogears

Gold Screws (Optional)

We can use Gold Screws to give your pickups a different look for a small up-charge.

Pickguard-Mounted Soapbar?

Most Soapbar Pickups are height-adjusted with screws that thread into the body.

Some Soapbar Pickups are mounted on the pickguard via a screw on either side. (Modern Les Paul Junior Tribute, Soapbar-equipped SG’s) Check this box if your guitar requires this modification. You’ll get 2 tabs to slip on the mounting tabs for threading your screws. Available in Gibson-Spacing only.

DIMENSIONS


See below for the estimated DCR and Polarity Information for our Hum-Cancelling P90.

The phase of this pickup is reversible with 2-Conductor With Shield lead.

Want sound clips and video? Read Below

SPECIFICATION VALUE
Neck Ohm Reading (Stock):15.5K*
Bridge Ohm Reading (Stock):16.8K*
Neck Polarity:Reversible with 2-Conductor Lead
Bridge Polarity:Reversible with 2-Conductor Lead
Magnet:USA-Made Bonded Neodymium
Wire:USA-Made 43 Gauge Single Poly Nylon
Bobbin Material:USA-Made Nylon Injection Mold
Recommended Pot Value:500K
String Spacing:50mm

* Due to the unique design of this pickup, ohm readings aren't very helpful. Our Stock Set is close to the Vintage P90 output.


All P90, No Hum.

Want to learn more about our Hum-Cancelling P90? Here's all the information you'll need:

Hum-Cancelling P90 FEATURES:

  • Lindy Fralin Original Design: True P90 Tone, No Hum
  • Multiple Outputs available for fine-tuning your Pickup’s voice
  • Strong and bold – lots of midrange and snarl
  • USA-made Neodymium Magnets for aggressive tone and output
  • Compensated Bridge for even volume across all pickups
  • Adjustable USA-Made Steel Pole pieces for fine-tuning string balance
  • Hand-wound with our “Sectioning” technique for unique, dynamic tone
  • Hand-built for unrivaled quality control
  • Backed by our 10-Year Warranty on manufacturing defects
  • Risk-Free 30-day exchange policy

Overview

The Fralin Hum Cancelling P90 is one of the best-selling models we make, and it’s easy to see why. Genuine P90 tone and dead-quiet performance? What’s not to love?

Whether you play Rock, Jazz, Country, R&B, or Funk, you will undoubtedly stand out in the mix with the pronounced pick attack, crystal-clear lows, and round highs. And the best part? Zero hum. Available in a Soapbar, Dogear, and Humbucker, you can rest assured knowing you can get the Fralin P90 tone in any guitar you have.

Sound

There are a few ways to cancel out the hum in a pickup. Some manufacturers feature a “stacked” coil design, which we believe leads to a lifeless and dull tone that lacks character. Lindy’s Hum Cancelling P90 features a Side-by-side coil design that is not stacked and attains a more accurate P90 tone that actually sounds like a P90.

Expect a vintage-voiced P90 tone, with a slightly thicker midrange and rounder highs. This pickup will undoubtedly push your amp hard and provide that snarly midrange and top-end “bark” we have come to expect from a P90. Suitable for many music styles, this pickup can scream and clean up nicely for jazz or blues.

Going even further, you can customize your tone by selecting Overwound and Underwound options. By overwinding a pickup, the tone gets thicker, darker, and dirtier. By underwinding a pickup, the pickup gets clearer and more articulate.

Speaking of versatility, are you looking for a jazzier tone? We can use Alnico 6 Magnets to taper the highs even more and offer you a softer sound. Are you searching for a cleaner and more Fender sparkle? Check out our Alnico Rod Version that features Alnico Rods for a Fender-type sparkle.

Our manufacturing process allows us to achieve unparalleled quality control.

Hum-Cancelling P90s consists of 100% USA-Made parts, including a precision injection mold, USA-Made Steel Screws, and Neodymium magnets. We use aggressive USA-Made Neodymium magnets to make this model scream. Each bobbin is carefully inspected and cleaned before winding.

We wind each pickup by hand, one at a time, using our proprietary “Sectioning” technique, which gives the pickup a sweet, clear tone. Finally, we wax-pot the pickup to prevent microphonics and preserve the pickup for years to come.


Tonal Graph for Hum-Cancelling P90:

The tone graph below for our Hum-Cancelling P90 features Lows, Midrange, Highs, and general Output.

HIGHS
MIDS
LOWS
OUTPUT

Video

Tech Specs

See below for the estimated DCR and Polarity Information for our Hum-Cancelling P90.

The phase of this pickup is reversible with 2-Conductor With Shield lead.

SPECIFICATION VALUE
Neck Ohm Reading (Stock):15.5K*
Bridge Ohm Reading (Stock):16.8K*
Neck Polarity:Reversible with 2-Conductor Lead
Bridge Polarity:Reversible with 2-Conductor Lead
Magnet:USA-Made Bonded Neodymium
Wire:USA-Made 43 Gauge Single Poly Nylon
Bobbin Material:USA-Made Nylon Injection Mold
Recommended Pot Value:500K
String Spacing:50mm

* Due to the unique design of this pickup, ohm readings aren't very helpful. Our Stock Set is close to the Vintage P90 output.

FAQs

FAQS:

  1. What’s the tonal difference between this and your Stock P90The Hum Cancelling P90 is slightly louder, darker, and thicker. It’s quicker to break up, and has no hum!
  2. What output do I choose? Our most popular set is the Stock Neck & Bridge. Going with a +5% output from Stock will thicken and darken the tone. Going with a -5% will clean up and reduce the midrange, making it sound more articulate and clear.
  3. What lead do I choose? This depends on your guitar and a few other things. Gibson Lead: Go with this if installing a set into a Gibson-style instrument, where each pickup has its respective volume pot. 2-Conductor: Go with this lead if buying a Single, or installing into a Fender-style instrument.
  4. What’s the String Spacing? 49.5mm.
  5. I don’t see what I’m looking for? We can do some custom work, for sure. However, we’re not tooled-up for certain things, like Nickel Dogear Covers. Contact us if you’re not seeing something you’re looking for.
  6. How far away from the strings does the pickup need to be? Push your Low E String down at the highest fret. Measure from the top of the pole piece to the bottom of the string. The ideal starting location should be 1/8″ on the bass string, and 1/16″ on the treble string when the High E string is pushed down at the highest fret.
  7. Wiring Diagrams? Here!

Sizing & Wiring Diagrams



FEATURES:
  • Lindy Fralin Original Design: True P90 Tone, No Hum
  • Multiple Outputs available for fine-tuning your Pickup’s voice
  • Strong and bold – lots of midrange and snarl
  • USA-made Neodymium Magnets for aggressive tone and output
  • Compensated Bridge for even volume across all pickups
  • Adjustable USA-Made Steel Pole pieces for fine-tuning string balance
  • Hand-wound with our “Sectioning” technique for unique, dynamic tone
  • Hand-built for unrivaled quality control
  • Backed by our 10-Year Warranty on manufacturing defects
  • Risk-Free 30-day exchange policy
Overview

The Fralin Hum Cancelling P90 is one of the best-selling models we make, and it’s easy to see why. Genuine P90 tone and dead-quiet performance? What’s not to love?

Whether you play Rock, Jazz, Country, R&B, or Funk, you will undoubtedly stand out in the mix with the pronounced pick attack, crystal-clear lows, and round highs. And the best part? Zero hum. Available in a Soapbar, Dogear, and Humbucker, you can rest assured knowing you can get the Fralin P90 tone in any guitar you have.

Sound

There are a few ways to cancel out the hum in a pickup. Some manufacturers feature a “stacked” coil design, which we believe leads to a lifeless and dull tone that lacks character. Lindy’s Hum Cancelling P90 features a Side-by-side coil design that is not stacked and attains a more accurate P90 tone that actually sounds like a P90.

Expect a vintage-voiced P90 tone, with a slightly thicker midrange and rounder highs. This pickup will undoubtedly push your amp hard and provide that snarly midrange and top-end “bark” we have come to expect from a P90. Suitable for many music styles, this pickup can scream and clean up nicely for jazz or blues.

Going even further, you can customize your tone by selecting Overwound and Underwound options. By overwinding a pickup, the tone gets thicker, darker, and dirtier. By underwinding a pickup, the pickup gets clearer and more articulate.

Speaking of versatility, are you looking for a jazzier tone? We can use Alnico 6 Magnets to taper the highs even more and offer you a softer sound. Are you searching for a cleaner and more Fender sparkle? Check out our Alnico Rod Version that features Alnico Rods for a Fender-type sparkle.

Our manufacturing process allows us to achieve unparalleled quality control.

Hum-Cancelling P90s consists of 100% USA-Made parts, including a precision injection mold, USA-Made Steel Screws, and Neodymium magnets. We use aggressive USA-Made Neodymium magnets to make this model scream. Each bobbin is carefully inspected and cleaned before winding.

We wind each pickup by hand, one at a time, using our proprietary “Sectioning” technique, which gives the pickup a sweet, clear tone. Finally, we wax-pot the pickup to prevent microphonics and preserve the pickup for years to come.


Tonal Graph for Hum-Cancelling P90:

The tone graph below for our Hum-Cancelling P90 features Lows, Midrange, Highs, and general Output.

HIGHS
MIDS
LOWS
OUTPUT
Video

Tech Specs

See below for the estimated DCR and Polarity Information for our Hum-Cancelling P90.

The phase of this pickup is reversible with 2-Conductor With Shield lead.

SPECIFICATION VALUE
Neck Ohm Reading (Stock):15.5K*
Bridge Ohm Reading (Stock):16.8K*
Neck Polarity:Reversible with 2-Conductor Lead
Bridge Polarity:Reversible with 2-Conductor Lead
Magnet:USA-Made Bonded Neodymium
Wire:USA-Made 43 Gauge Single Poly Nylon
Bobbin Material:USA-Made Nylon Injection Mold
Recommended Pot Value:500K
String Spacing:50mm

* Due to the unique design of this pickup, ohm readings aren't very helpful. Our Stock Set is close to the Vintage P90 output.

FAQs

FAQS:

  1. What’s the tonal difference between this and your Stock P90The Hum Cancelling P90 is slightly louder, darker, and thicker. It’s quicker to break up, and has no hum!
  2. What output do I choose? Our most popular set is the Stock Neck & Bridge. Going with a +5% output from Stock will thicken and darken the tone. Going with a -5% will clean up and reduce the midrange, making it sound more articulate and clear.
  3. What lead do I choose? This depends on your guitar and a few other things. Gibson Lead: Go with this if installing a set into a Gibson-style instrument, where each pickup has its respective volume pot. 2-Conductor: Go with this lead if buying a Single, or installing into a Fender-style instrument.
  4. What’s the String Spacing? 49.5mm.
  5. I don’t see what I’m looking for? We can do some custom work, for sure. However, we’re not tooled-up for certain things, like Nickel Dogear Covers. Contact us if you’re not seeing something you’re looking for.
  6. How far away from the strings does the pickup need to be? Push your Low E String down at the highest fret. Measure from the top of the pole piece to the bottom of the string. The ideal starting location should be 1/8″ on the bass string, and 1/16″ on the treble string when the High E string is pushed down at the highest fret.
  7. Wiring Diagrams? Here!
Sizing & Wiring Diagrams
