Prewired Telecaster Custom ’72 Pickguard

Easier Than Ever


  • Hum-Cancelling
  • Clean & Articulate
  • Traditional Appearance
  • Vintage Output

Create a unique Telecaster Custom ’72 pickguard tailored to your preferences rather than a generic one! Built with our Wide Range Humbucker Neck, your choice of Bridge Pickup, CTS® Pots, a Switchcraft Toggle Switch, and our custom Tone Caps, rest assured that your Prewired Tele Custom ’72 Pickguard is built with the best of the best.


Customize your Prewired Telecaster Custom '72 Pickguard:


Due to the nature of Raw Nickel, Raw Nickel may contain slight cosemetic defects or abrasions.


We recommend using 2-Conductor With Shield Lead when purchasing a single pickup. 2-Conductor lead allows you to reverse the phase should you have phase issues. Learn About Lead Choice


While we do our best to match double-white bobbins, there may be subtle differences in color due to different dye lots from the manufacturer.

Upgrade To A Prewired Pickguard

Express Checkout

Skip the checkout and buy now. Purchases made through Express Checkout are bound by our Terms and Conditions.

More Payment Options Offered At Checkout:

Heads up!

We may make minor changes to your order to optimize your pickguard's wiring with your pickup selection. However, we will not make any drastic changes without your consent.

What's Included?

Fully prewired and assembled and includes a set of Knobs, a Matching Switch Tip, and Mounting Hardware.

Prewired Telecaster Custom '72 Pickguard Info:

Want to learn more about our Prewired Telecaster Custom '72 Pickguard? Here's all the information you'll need:


At Fralin Pickups, we’re always trying to make you sound better. Our Lindy Fralin Prewired Telecaster Deluxe Pickguard offers the best tone and highest quality available. We use our world-famous pickups with the best ingredients we can get. We hand-wire your Tele pickguard with painstaking attention to detail.

Furthermore, you can customize your pickguard exactly how you want it! With our Telecaster Deluxe Pickguard, you can have the famous Fralin tone and ease of mind: All you need to do is solder a few wires, screw it in, string it up, and you’re off rocking!


  • The ultimate “Build Your Own” Telecaster Deluxe ’72 Pickguard
  • Our Wide Range Humbucker Neck featuring our new Fralin-Branded cover for a classic, but sleek look
  • Your choice of Bridge Pickup, optimized to work seamlessly with the Neck pickup
  • USA-Made pickups & electronics for superior quality
  • Hand-wired with USA-Made vintage cloth lead for a traditional look
  • Fully customizable – from appearance to function
  • Hand-assembled, signed and dated by our pickguard craftsman
  • Easy installation – only 3 wires to solder
  • 10-year warranty on materials and craftsmanship


A Note On Soundclips:

Our Sound Clips are played from the Neck first and the Bridge last. Please note the Waveforms when comparing – the third “waveform” will be the Bridge pickup.

Be mindful when selecting outputs

The Wide Range humbucker is a strong pickup in terms of output. We recommend the High Output or Steel Pole 43, or the Split Blade or Split Steel Pole to match. The Vintage Hot, Blues Special and Steel Pole 42 will sound a bit out of balance, output-wise.

Sound Samples for Prewired Telecaster Custom ’72 Pickguard:
Compare Outputs

We have 6 outputs of our Prewired Telecaster Custom ’72 Pickguard. Compare them below.

About these Sound Clips:

All sound samples are played from Neck Position First and Bridge Position Last.


Installation is super simple! We’ve taken the liberty of soldering all connections possible on the guitar, even the output jack! All that you’ll need to do is solder the Bridge Pickup to the controls. Here’s where the wires go:Telecaster Custom Install

Installation Note:

While we’ve made the installation as easy as possible, If you don’t feel comfortable soldering, take your new Prewired Pickguard to an experienced luthier for installation.

Pickup Height:

Once your new pickguard is installed and strung up, it’s time to set your pickup height! Here’s an article on how to do that: How To Properly Set Pickup Height

Tech Specs:

Pot Manufacturer:CTS®
Pot Value:500K (Recommended)
Switch Manufacturer:Switchcraft®

More Information:

Prewired Telecaster Custom ’72 Pickguard FAQ's

General FAQs

Here are quick answers to common questions we get:

    Product FAQ's

    These are frequently asked questions about our Prewired Telecaster Custom ’72 Pickguard. If you have a question that you don't see listed here, click "Ask A Question" in the Quick Links section above.

    • Which Tone Cap do I select?

      We always recommend 0.022mfd as the Tone Cap value. A larger capacitance value means more roll-off, a lower capacitance value means less roll-off.

    • Can I return this pickguard?

      No – all pickguards are built to order, and are non-returnable.

    • Can you coil-split the Wide Range Humbucker?

      While it’s possible, we don’t recommend it. There are two main reasons why:

      1. The Wide Range Humbucker consists of two low-wind coils. These coils by themselves don’t produce a usable output.
      2. Half of the Coil’s magnets are under the cover, without the ability to adjust them easily. This will yield an unbalanced tone.

There are no reviews yet.

Be the first to review “Prewired Telecaster Custom ’72 Pickguard”

Leave a review for our Prewired Telecaster Custom '72 Pickguard

Your email address will not be published. Required fields are marked *

  • Please note that while we strive to provide the most accurate color representation possible, different computer monitors, manufacturer dye lots, and other circumstances may prevent the color from matching perfectly.
  • Since we cannot guarantee color matching, we cannot provide a return to you if you are unhappy with the color matching of our Prewired Telecaster Custom ’72 Pickguard.
  • Our parts and wire lengths are designed to work seamlessly with our Prewired Telecaster Custom ’72 Pickguard. Due to various guitar and instrument designs, we cannot guarantee that our parts will fit properly, and due to this, we do not offer Wiring Harnesses.
